QSN Controller
Centralized network level control
Operators need network-wide visibility and control that allows quantum-safe infrastructure to be managed alongside established network operations. Toshiba QSN Controller provides a single, centralized point to visualise, configure and control QKD systems across the network. As a dedicated Software-Defined Networking (SDN) controller, it enables high levels of automation and communication to simplify deployment, expansion and reconfiguration as requirements change.
Turn complexity into coordinated control
Standards-based interfaces support integration with classical network infrastructure, higher-level orchestration and other QKD networks. The QSN Controller brings network-level control and automation together within the wider QSN Platform, helping operators scale without fragmented management and reducing the operational complexity and risk of the quantum-safe networking transition.
Highlights
Features & Benefits
Visualize and control the whole network
Monitor individual systems or the wider network from a single control point.
Simplify deployment and change
Centralized configuration and automation help operators deploy, expand and reconfigure quantum-safe networks consistently, reducing repetitive manual processes as deployments grow.
Integrate with existing operations
Standards-based SDN interfaces, including ETSI GS QKD 015 and ETSI GS QKD 018, support integration with classical network infrastructure, higher-level orchestration and other QKD networks.
Scale without fragmented management
By bringing network-wide control into a single SDN layer, the QSN Controller helps operators manage larger and multi-vendor quantum-safe network deployments alongside established network operations, simplifying management as the network expands.
Specifications
- Model
- Toshiba QSN Link 1550 / Toshiba QSN Link 1310
- Type
- QKD transmitter and receiver pair
- Primary applications
- Data centre interconnect
- Quantum and optical channel
- Protocol: Toshiba T12 (efficient BB84 with decoy states and phase encoding)
- Quantum wavelength: C band 1550 nm / O band 1310 nm
- Classical wavelengths: 1530.33 nm (channel 59) and 1529.55 nm (channel 60); SFP’s are changeable to any C-band channel aligned to the ITU-T grid between 1530 nm and 1565 nm
- Fiber requirement: Two fibre or single fibre operation (with 1310 nm variant and QSN Multiplexer)
- Entropy source: QRNG
- Performance
- Secret bit rate: 150 kbps at 10 dB (specified), 300 kbps (typical)
- Maximum loss budget: 30 dB
- Maximum distance: 150 km (1550 nm), 90 km (1310 nm)
- Security parameter: <1 × 10⁻¹⁰
- Monitoring and security
- Management: SNMP v2/v3, GUI, CLI, REST API
- Interfaces: 2 × LC optical (TX/RX), 2 × SFP QKD service channels), 2 × RJ45 for management and key delivery, 2 × SFP (for optional optical management and key delivery interface), VGA and 2 × USB for local access
- Tamper detection: hardware-based with alarming
- Key delivery / SDN: ETSI GS QKD 014, Cisco SKIP (optional), ETSI GS QKD 015
- Key management
- Optional integrated Key Delivery System for network-wide key delivery
- Physical and environmental
- Form factor: 19-inch rack, 2U
- Dimensions: 482 × 606 × 87 mm
- Power: 1+1 redundant hot-swappable PSU (100–240 VAC or –48 VDC)
- Temperature: operating 10°C to 35°C; non-operating –10°C to 60°C
- Humidity: operating up to 80% RH; non-operating up to 90% RH
- Connectors: LC/PC
- Standards
- CE, FCC, FDA, ICES, VCCI, IEC 62368-1, IEC 60825-1/-2, IEC 63000, others TBA
